Inspection and control of SSL-encrypted traffic includes a number of sequential steps that can be summarized as follows:
1. Identify the protocol used with SSL. When the protocol is identified, DeviceLock checks whether the user is allowed to connect via that protocol (see
diagram in the
Managed Access Control section earlier in this document).
3. Check whether traffic is allowed by a white list rule created for the Any protocol (see
Protocol option description in
Managing Protocols White List).
4. Check whether traffic is allowed by a firewall rule.
In the following diagram you can see how DeviceLock inspects SSL-encrypted traffic and applies appropriate security measures based on the policies defined.
